Factory price 602035 Lithium Polymer Battery Pack 3.7V 400mah Li-polymer Battery
Lipo battery Specification:
| Product Name | 602035 400mAh Li-polymer battery |
| Battery Type | Lithium polymer battery |
| Power Wh: | 1.48Wh | |
| Accembly Composed Type | 1S1p/ 1 cell | |
| Nominal Capacity | 400 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 200mA | @0.5C charge |
| Max. charge current | 400 mA | @1C charge |
| Standard Discharge Current | 200 mA | @0.5C discharge |
| Max. Discharge Current | 400 mA | @1C discharge |
| Resistance | ＜80 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 7 g | |
| Dimensions(T.W.L.) | 6.0*20*35 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month |
| Protection Function(PCM) | Over charge, Over discharge,
Over load, Short Circuit |
| Warranty | 12 Months |
Specification:
• High quality 3.7 li po battery
• no memory effect and rechargeable
• Higher energy density
• Long cycle life :>500 times
• Short circuit protection and over current protection are avaliable
• Avaliable terminals: soldering tabs, wires, connectors
Appliactions of 602035 3.7V 400mah Lithium battery with PCM
1. Telecommunications: Cellular phone, interphone, blue tooth earphone.
2. Video Devices: MP3/MP4/MP5, digital camera, portable DVD, portable television
3. Portable Devices: GPS,PDA, E-book ,PMP, PSP, portable medical device etc.
4. Illuminate Devices: Miner lamp, search light.
5. Others: Electric Toys, RC models
