Lipo 603040 3.7v 650mah Custom-made Lithium ion Polymer Battery
Lipo battery Specification:
| Product Name | 603040 650mAh Lipo battery |
| Battery Type | Lithium polymer battery |
| PCM | Available | |
| Accembly Composed Type | 1S1p/ 1 cell | |
| Nominal Capacity | 650 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 375mA | @0.5C charge |
| Max. charge current | 650 mA | @1C charge |
| Standard Discharge Current | 375 mA | @0.5C discharge |
| Max. Discharge Current | 650 mA | @1C discharge |
| Resistance | ＜100 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 16 g | |
| Dimensions(T.W.L.) | 6.0*30*40 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month |
| Protection Function(PCM) | Over charge, Over discharge,
Over load, Short Circuit |
| Warranty | 12 Months |
Key Features
- Intelligent Battery Pack Design
- Environmental Friendly Chemistry
- High Energy Density
- High Power Density
- Fast Charge Capability
- Excellent Cycle Life
1. OEM/ODM accepted;
2. Ultra thin battery cell 0.6-2.5mm available;
3. Full inspection before shipment;
4. Protection system: all adopts the original chip from Japan and USA;
5. Longer storage life than NiMH Batteries;
6. Light weight and higher energy density than any rechargeable battery.
Warranty:
1 year from the date of shipment for 3.7v 650mah li-polymer battery.
Services :
1.Rich experience
We have specialized in this field for many years with rich experience and good reputation.
Our factory has well-equipped modern office ,dust-free workshop, first-class production and testing equipments, mature production lines and practice ataff members.
2. OEM service
We offer custom OEM service, we offer custom banding options for our current product lines.
3. Quality Assurance
We provide mid-to-high-end products with CE,R0HS , FCC certifications.
4. After sale
We offer one year warranty , fast response, professional solution
